RJLSE6306101T2
1
-
- 個
２営業日以内に回答いたします
RJLSE6306101T2 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | RJLSE6306101T2 |
|---|---|
| メーカー | AMPHENOL |
| Body Breadth | 0.462 inch |
| Body Depth | 0.665 inch |
| Body Length | 0.52 inch |
| Body/Shell Style | JACK |
| Connector Type | TELECOM AND DATACOM CONNECTOR |
| Contact Finish - Mating | GOLD (50) |
| Contact Finish - Termination | Matte Tin (Sn) |
| Contact Gender | FEMALE |
| Contact Material | PHOSPHOR BRONZE |
| Contact Pattern | RECTANGULAR |
| Contact Resistance | 20 mohm |
| Contact Style | TELCOM, MODULAR |
| Dielectric Withstanding Voltage | 1000VAC V |
| Empty Shell | NO |
| Filter Feature | NO |
| Insertion Force-Max | 22.24 N |
| Insulation Resistance | 5000000000 ohm |
| Insulator Color | BLACK |
| JESD-609 Code | e3 |
| Mixed Contacts | NO |
| Mounting Style | RIGHT ANGLE |
| Mounting Type | BOARD |
| Number Of Connectors | ONE |
| Number Of PCB Rows | 2 |
| Number of Ports | 1 |
| Number of Rows Loaded | 1 |
| Operating Temperature-Max | 85 Cel |
| Operating Temperature-Min | -40 Cel |
| Option | GENERAL PURPOSE |
| PCB Contact Pattern | STAGGERED |
| Plating Thickness | 50u inch |
| Rated Current (Signal) | 1.5 A |
| Reference Standard | UL |
| Termination Type | SURFACE MOUNT |
| Total Number of Contacts | 6 |
| UL Flammability Code | 94V-0 |
| Withdrawl Force-Min | 88.964 N |
| 会社名称 | Amphenol Adronics, Inc. |
|---|---|
| 所在地 | 358 Hall Avenue Wallingford, CT 06492,USA |
| URL | http://www.amphenol.com/ |
