MS3116F22-55S データシート

Name: MS3116F22-55S
Brand: AMPHENOL
SKU: 230364488-0000-0000-0000

MS3116F22-55S - AMPHENOL の商品詳細ページです。

２営業日以内に回答いたします

MS3116F22-55S の詳細情報

型番	MS3116F22-55S
メーカー	AMPHENOL
データシート
Additional Feature	STANDARD: MIL-C-26482, POLARIZATION AVAILABLE
Backshell Type	SOLID
Body/Shell Style	PLUG
Connector Type	MIL SERIES CIRCULAR CONNECTOR
Contact Finish - Mating	GOLD
Contact Finish - Termination	GOLD
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Quantities	55
Contact Sizes	20
Coupling Type	BAYONET
DIN Conformance	NO
Degrees of Rotation	0
Description	STRAIGHT PLUG
Empty Shell	NO
Environmental Characteristics	CORROSION/ENVIRONMENT/FLUID RESISTANT
Filter Feature	NO
IEC Conformance	NO
Insulator Material	NEOPRENE RUBBER
JESD-609 Code	e4
MIL Conformance	YES
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Type	CABLE
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
Polarization	N
Shell Finish	CADMIUM
Shell Material	ALUMINUM ALLOY
Shell Size	22
Termination Type	SOLDER
Total Number of Contacts	55
Unique Insert Number	22-55
