- 352332-1
352332-1
1
-
- 個
２営業日以内に回答いたします
352332-1 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | 352332-1 |
|---|---|
| メーカー | AMP |
| Additional Feature | Z-PACK |
| Board Mounting Option | PEG |
| Body Breadth | 0.606 inch |
| Body Depth | 0.53 inch |
| Body Length | 1.965 inch |
| Body/Shell Style | PLUG |
| Connector Type | BOARD CONNECTOR |
| Contact Finish - Mating | NOT SPECIFIED |
| Contact Finish - Termination | NOT APPLICABLE |
| Contact Gender | MALE |
| Contact Material | NOT SPECIFIED |
| Contact Pattern | RECTANGULAR |
| Contact Resistance | 20 mohm |
| Contact Style | SQ PIN-SKT |
| DIN Conformance | NO |
| Durability | 250 Cycles |
| EMI Shielded | YES |
| Empty Shell | YES |
| Filter Feature | NO |
| IEC Conformance | NO |
| Insertion Force-Max | .7506 N |
| Insulation Resistance | 10000000000 ohm |
| Insulator Color | GRAY |
| Insulator Material | GLASS FILLED POLYESTER |
| MIL Conformance | NO |
| Mains Connector Rating | 1.5A |
| Manufacturer Series | 352332 |
| Mating Contact Pitch | 0.079 inch |
| Mating Contact Row Spacing | 0.079 inch |
| Mixed Contacts | NO |
| Mounting Option 1 | LOCKING |
| Mounting Style | STRAIGHT |
| Mounting Type | BOARD |
| Number Of Connectors | ONE |
| Number Of PCB Rows | 7 |
| Number of Ports | 1 |
| Number of Rows Loaded | 7 |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -55 Cel |
| Option | GENERAL PURPOSE |
| PCB Contact Pattern | RECTANGULAR |
| PCB Contact Row Spacing | 2.0066 mm |
| Panel Mount | NO |
| Plating Thickness | 15u inch |
| Polarization Key | POLARIZED HOUSING |
| Rated Current (Signal) | 1.5 A |
| Reference Standard | UL |
| Reliability | COMMERCIAL |
| Sub Category | Headers and Edge Type Connectors |
| Terminal Pitch | 2 mm |
| 会社名称 | TE Connectivity Ltd. |
|---|---|
| 設立 | 1941 |
| 所在地 | Rheinstrasse 20 Ch-8200 Schaffhausen Switzerland |
| URL | http://www.te.com/ |
