350690-7 データシート

Name: 350690-7
Brand: AMP
SKU: 40185052-0000-0000-0000

350690-7 - AMP の商品詳細ページです。

２営業日以内に回答いたします

350690-7 の詳細情報

型番	350690-7
メーカー	AMP
データシート
Additional Feature	UNDERPLATING THICKNESS (50)
Approvals	CSA; UL V
Assembly Item Name	CONTACT
Cable Entry-Max	0.1 inch
Cable Entry-Min	0.04 inch
Cable Types	DISCRETE WIRE
Connector Support Type	CONNECTOR ACCESSORY
Construction	STRANDED
Contact Design	SOLID
Contact Gender	MALE
Cross Section Area	0.8 mm2
DIN Conformance	NO
Design Use	POWER
Finish Thickness	30
IEC Conformance	NO
MIL Conformance	NO
Material	BRASS
Mounting Style	STRAIGHT
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Rated Current	19 A
Rated Voltage	600 V
Rated Voltage (AC)	600 V
Terminal Type	CRIMP
Used With	UNIVERSAL MATE-N-LOK PLUG AND CAP HOUSING
Wire Gauge	18 AWG
Wire Size-Max	18 AWG
Wire Size-Min	24 AWG

会社名称	TE Connectivity Ltd.
設立	1941
所在地	Rheinstrasse 20 Ch-8200 Schaffhausen Switzerland
URL	http://www.te.com/
