350689-1 データシート

Name: 350689-1
Brand: AMP
SKU: 40184897-0000-0000-0000

350689-1 - AMP の商品詳細ページです。

２営業日以内に回答いたします

350689-1 の詳細情報

型番	350689-1
メーカー	AMP
データシート
Additional Feature	CONTACT FINISH: TIN
Approvals	CSA; UL; VDE V
Assembly Item Name	CONTACT
Cable Entry-Max	0.1 inch
Cable Entry-Min	0.04 inch
Cable Types	DISCRETE WIRE
Connector Support Type	CONNECTOR ACCESSORY
Construction	STRANDED
Contact Gender	FEMALE
Contact Style	ROUND PIN-SOCKET
Cross Section Area	0.8 mm2
DIN Conformance	NO
Design Use	POWER
IEC Conformance	NO
MIL Conformance	NO
Material	BRASS
Mfr Name	TYCO ELECTRONICS AMP
Mfr P/N	350689-1
Mounting Style	STRAIGHT
New Category	Assembly Items
New Part Type	CONNECTOR_SUPPORT
Old Category	Terminals and Terminal Blocks
Old Part Type	TERMINALS_AND_TERMINAL_BLOCKS
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Part Objectid	2060809538
Rated Current	19 A
Rated Voltage	600 V
Rated Voltage (AC)	600 V
Terminal Type	CRIMP
Used With	UNIVERSAL MATE-N-LOK PLUG AND CAP HOUSING
Wire Gauge	18 AWG
Wire Size-Max	18 AWG
Wire Size-Min	24 AWG
