2-5767004-2 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番2-5767004-2
メーカーAMP
データシートProduct_list_pdf
Board Mounting Option BOARD LOCK
Body Breadth 0.272 inch
Body Depth 0.236 inch
Body Length 1 inch
Body/Shell Style RECEPTACLE
Characteristic Impedance 50 ohm
Connector Type BOARD STACKING CONNECTOR
Contact Arrangement S38P1
Contact Finish - Mating NOT SPECIFIED
Contact Finish - Termination MATTE TIN OVER NICKEL
Contact Gender FEMALE
Contact Material COPPER ALLOY
Contact Pattern RECTANGULAR
Contact Style CENTRONIC
DIN Conformance NO
Dielectric Withstanding Voltage 500VAC V
EMI Shielded NO
Empty Shell YES
Filter Feature NO
IEC Conformance NO
Insulation Resistance 2000000 ohm
Insulator Color BLACK
Insulator Material LIQUID CRYSTAL POLYMER
JESD-609 Code e3
MIL Conformance NO
Mains Connector Rating 11.5A
Manufacturer Series 5767004
Mating Contact Pitch 0.025 inch
Mating Contact Row Spacing 0.228 inch
Mixed Contacts NO
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Mounting Type BOARD
Number Of Connectors ONE
Number Of PCB Rows 2
Number of Ports 1
Number of Rows Loaded 2
Operating Temperature-Max 125 Cel
Operating Temperature-Min -55 Cel
Option GENERAL PURPOSE
PCB Contact Pattern RECTANGULAR
PCB Contact Row Spacing 7.0612 mm
Panel Mount NO
Plating Thickness 29.92u inch
Polarization Key POLARIZED HOUSING
Rated Current (Signal) 11.5 A
Rated Voltage 1 V
Reference Standard CSA, UL
Reliability COMMERCIAL
Terminal Pitch .64 mm
