2-178802-3 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番2-178802-3
メーカーAMP
データシートProduct_list_pdf
Additional Feature COMPATIBLE CONTACTS: 175284-2; 175284-3; 175284-5; 175287-2; 175287-3
Body Breadth 0.5 inch
Body Depth 1.323 inch
Body Length 1.575 inch
Body/Shell Style PLUG
Connector Type RECTANGULAR POWER CONNECTOR
Contact Arrangement S0P3
Contact Finish - Mating NOT SPECIFIED
Contact Finish - Termination NOT APPLICABLE
Contact Gender MALE
Contact Material NOT SPECIFIED
DIN Conformance NO
EMI Shielded NO
Empty Shell YES
Filter Feature NO
IEC Conformance NO
Insulation Resistance 100000000 ohm
Insulator Color BLACK
Insulator Material GLASS FILLED POLYESTER
MIL Conformance NO
Mains Connector Rating 115/230VAC
Mating Information 2-178288-3
Mixed Contacts NO
Mounting Option 1 M3
Mounting Option 2 SCREW
Mounting Style STRAIGHT
Mounting Type PANEL
Number Of Connectors ONE
Number of Ports 1
Number of Rows Loaded 1
Operating Temperature-Max 105 Cel
Operating Temperature-Min -55 Cel
Option GENERAL PURPOSE
Panel Mount NO
Reference Standard CSA, UL
Reliability COMMERCIAL
Shell Material NYLON
Sub Category Headers and Edge Type Connectors
Terminal Pitch 3.81 mm
Termination Type CRIMP
Total Number of Contacts 3
UL Flammability Code 94V-0
