2-178288-3 データシート Amp

2-178288-3
2-178288-3

2-178288-3 - AMP の商品詳細ページです。

1

202時間33分後 以内に見積もり依頼を頂ければ、
05月08日(水) 9:00 までに見積もり回答いたします。

  • 個
この商品のお問い合わせ

2-178288-3 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番2-178288-3
メーカーAMP
データシートProduct_list_pdf
Additional Feature COMPATIBLE CONTACTS: 175194-2; 175194-3; 175194-5; 175216-2; 175216-3
Body Breadth 0.281 inch
Body Depth 0.898 inch
Body Length 1.054 inch
Body/Shell Style RECEPTACLE
Connector Type RECTANGULAR POWER CONNECTOR
Contact Arrangement S0P3
Contact Finish - Mating NOT SPECIFIED
Contact Gender FEMALE
Contact Material NOT SPECIFIED
DIN Conformance NO
EMI Shielded NO
Empty Shell YES
Filter Feature NO
IEC Conformance NO
Insertion Force-Max 4.8928 N
Insulation Resistance 100000000 ohm
Insulator Color BLACK
Insulator Material POLYESTER
MIL Conformance NO
Mains Connector Rating 115/230VAC
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Option 1 LATCH
Mounting Option 2 LOCKING
Mounting Style STRAIGHT
Mounting Type CABLE
Number Of Connectors ONE
Number of Ports 1
Number of Rows Loaded 1
Operating Temperature-Max 105 Cel
Operating Temperature-Min -55 Cel
Option GENERAL PURPOSE
Panel Mount NO
Reference Standard CSA, UL
Reliability COMMERCIAL
Sub Category Headers and Edge Type Connectors
Terminal Pitch 3.81 mm
Termination Type CRIMP
Total Number of Contacts 3
UL Flammability Code 94V-0
Withdrawl Force-Min .28912 N
会社名称TE Connectivity Ltd.
設立1941
所在地Rheinstrasse 20 Ch-8200 Schaffhausen Switzerland
URLhttp://www.te.com/
