1-917659-5 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番1-917659-5
メーカーAMP
データシートProduct_list_pdf
Additional Feature COMPATIBLE CONTACTS: 175194-2; 175194-3; 175194-5; 175216-2; 175216-3
Body Breadth 0.581 inch
Body Depth 0.897 inch
Body Length 1.474 inch
Body/Shell Style RECEPTACLE
Connector Type RECTANGULAR POWER CONNECTOR
Contact Design PREASSEM CONN
Contact Finish - Mating NOT SPECIFIED
Contact Finish - Termination NOT APPLICABLE
Contact Gender FEMALE
Contact Material NOT SPECIFIED
Contact Pattern RECTANGULAR
DIN Conformance NO
EMI Shielded NO
Empty Shell YES
Filter Feature NO
IEC Conformance NO
Insertion Force-Max 9.7856 N
Insulation Resistance 1000000000 ohm
Insulator Color BLACK
Insulator Material POLYESTER
MIL Conformance NO
Mains Connector Rating 115/230VAC
Mating Contact Pitch 0.2 inch
Mating Contact Row Spacing 0.299 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Option 1 LOCKING
Mounting Type CABLE
Number Of Connectors ONE
Number of Ports 1
Number of Rows Loaded 2
Operating Temperature-Max 105 Cel
Operating Temperature-Min -55 Cel
Option GENERAL PURPOSE
Panel Mount NO
Polarization Key POLARIZED HOUSING
Reference Standard CSA, UL
Reliability COMMERCIAL
Sub Category Headers and Edge Type Connectors
Terminal Pitch 3.81 mm
Termination Type CRIMP
Total Number of Contacts 10
UL Flammability Code 94V-0
