178307-2 データシート

Name: 178307-2
Brand: AMP
SKU: 400052835-0000-0000-0000

178307-2 - AMP の商品詳細ページです。

２営業日以内に回答いたします

178307-2 の詳細情報

型番	178307-2
メーカー	AMP
データシート
Additional Feature	ROHS AND ELV COMPL W/TUBE PKG
Board Mounting Option	PEG
Body Breadth	0.134 inch
Body Depth	0.059 inch
Body Length	1.601 inch
Body/Shell Style	RECEPTACLE
Connector Type	BOARD CONNECTOR
Contact Arrangement	S0P16
Contact Finish - Mating	AU
Contact Finish - Termination	Gold (Au)
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	424VAC V
Durability	500 Cycles
EMI Shielded	NO
Empty Shell	YES
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	4.8928 N
Insulation Resistance	100000000 ohm
Insulator Color	BLACK
Insulator Material	GLASS FILLED POLYESTER
JESD-609 Code	e4
MIL Conformance	NO
Mains Connector Rating	8A
Manufacturer Series	178
Mating Contact Pitch	0.05 inch
Mating Contact Row Spacing	0.05 inch
Mating Information	178289-7
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Rows Loaded	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	3.0988 mm
Rated Current (Signal)	1 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	1.27 mm
Termination Type	SOLDER
Total Number of Contacts	16
