177905-6 Amp

177905-6 - AMP の商品詳細ページです。

1
177905-6
  • 177905-6
  • 177905-6
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

177905-6 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番177905-6
メーカーAMP
Additional Feature COMPATIBLE CONTACTS: 177914-1; 177914-2; 177915-1; 179592-1; 179592-2
Body Breadth 0.634 inch
Body Depth 0.811 inch
Body Length 0.703 inch
Body/Shell Style PLUG
Connector Type RECTANGULAR POWER CONNECTOR
Contact Arrangement S0P12
Contact Finish - Mating NOT SPECIFIED
Contact Finish - Termination NOT APPLICABLE
Contact Gender FEMALE
Contact Material NOT SPECIFIED
Contact Resistance 20 mohm
Contact Style SQ PIN-SKT
DIN Conformance NO
EMI Shielded NO
Empty Shell YES
Filter Feature NO
IEC Conformance NO
Insulation Resistance 1000000000 ohm
Insulator Color BLUE
Insulator Material POLYAMIDE66
MIL Conformance NO
Mains Connector Rating 115/230VAC
Mating Contact Row Spacing 0.181 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Option 1 LATCH
Mounting Option 2 LOCKING
Mounting Style STRAIGHT
Mounting Type CABLE
Number Of Connectors ONE
Number of Ports 1
Number of Rows Loaded 3
Operating Temperature-Max 105 Cel
Operating Temperature-Min -30 Cel
Option GENERAL PURPOSE
Panel Mount NO
Rated Current (Signal) 10 A
Reference Standard UL
Reliability COMMERCIAL
Shell Material POLYAMIDE66
Sub Category Headers and Edge Type Connectors
Terminal Pitch 3.96 mm
Termination Type CRIMP
Total Number of Contacts 12
UL Flammability Code 94V-0
会社名称TE Connectivity Ltd.
設立1941
所在地Rheinstrasse 20 Ch-8200 Schaffhausen Switzerland
URLhttp://www.te.com/

177905-6のレビュー

177905-6 のご注文について
