174053-2 の詳細情報

型番	174053-2
メーカー	AMP
データシート
Additional Feature	MULTILOCK
Body Breadth	1.378 inch
Body Depth	0.831 inch
Body Length	0.854 inch
Body/Shell Style	RECEPTACLE
Connector Type	COMBINATION LINE CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	TIN
Contact Gender	MALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Durability	50 Cycles
EMI Shielded	NO
Empty Shell	YES
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	5.3376 N
Insulation Resistance	100000000 ohm
Insulator Color	BLACK
Insulator Material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
JESD-609 Code	e3
MIL Conformance	NO
Mains Connector Rating	115/230VAC
Mating Contact Pitch	0.098 inch
Mating Contact Row Spacing	0.205 inch
Mating Information	174046-2
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Option 2	MOUNTING FLANGE
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Ports	1
Number of Rows Loaded	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-30 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	2.9972 mm
Panel Mount	NO
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	3 A
Rated Voltage	12 V
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Length	0.157 inch
Terminal Pitch	2.5 mm
