型番 | 172157-1 |
---|---|
メーカー | AMP |
データシート | |
Additional Feature | MATE-N-LOK, COMPETIBLE CONTACTS: 170359-1; 170359-3; 170359-4; 170361-1; 170361-3; 170361-4 |
Body Breadth | 0.22 inch |
Body Depth | 0.465 inch |
Body Length | 0.465 inch |
Body/Shell Style | RECEPTACLE |
Connector Type | POWER CONNECTOR |
Contact Arrangement | S0P2 |
Contact Finish - Mating | NOT SPECIFIED |
Contact Finish - Termination | NOT APPLICABLE |
Contact Gender | MALE |
Contact Material | NOT SPECIFIED |
Contact Pattern | RECTANGULAR |
Contact Resistance | 10 mohm |
Contact Style | RND PIN-SKT |
DIN Conformance | NO |
Durability | 20 Cycles |
EMI Shielded | NO |
Empty Shell | YES |
Filter Feature | NO |
IEC Conformance | NO |
Insulation Resistance | 100000000 ohm |
Insulator Color | NATURAL |
Insulator Material | POLYAMIDE66 |
MIL Conformance | NO |
Mains Connector Rating | 115/230VAC |
Mating Information | MULTIPLE MATING PARTS AVAILABLE |
Mixed Contacts | NO |
Mounting Option 1 | DETENT |
Mounting Option 2 | LOCKING |
Mounting Style | STRAIGHT |
Mounting Type | PANEL |
Number Of Connectors | ONE |
Number of Ports | 1 |
Number of Rows Loaded | 1 |
Operating Temperature-Max | 105 Cel |
Operating Temperature-Min | -20 Cel |
Option | GENERAL PURPOSE |
Panel Mount | NO |
Rated Voltage | 600 V |
Reference Standard | CSA, UL |
Reliability | COMMERCIAL |
Shell Material | NYLON66 |
Sub Category | Headers and Edge Type Connectors |
Terminal Pitch | 4.2 mm |
Termination Type | CRIMP |
Total Number of Contacts | 2 |
UL Flammability Code | 94V-0 |
Withdrawl Force-Min | .973 N |
会社名称 | TE Connectivity Ltd. |
---|---|
設立 | 1941 |
所在地 | Rheinstrasse 20 Ch-8200 Schaffhausen Switzerland |
URL | http://www.te.com/ |
172157-1 - AMP の商品詳細ページです。
