1-178313-2 の詳細情報

型番	1-178313-2
メーカー	AMP
データシート
Additional Feature	ROHS AND ELV COMPLIANT
Board Mounting Option	SOLDERABLE RETENTION CLIPS
Body Breadth	0.368 inch
Body Depth	0.85 inch
Body Length	0.851 inch
Body/Shell Style	RECEPTACLE
Connector Type	RECTANGULAR POWER CONNECTOR
Contact Arrangement	S0P3
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	NOT APPLICABLE
Contact Gender	MALE
Contact Material	COPPER ALLOY
DIN Conformance	NO
Durability	500 Cycles
EMI Shielded	NO
Empty Shell	YES
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	4.8928 N
Insulation Resistance	100000000 ohm
Insulator Color	BLACK
Insulator Material	GLASS FILLED POLYESTER
MIL Conformance	NO
Mains Connector Rating	12A
Mating Information	1-178288-3
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number of Ports	1
Number of Rows Loaded	1
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
Panel Mount	NO
Plating Thickness	15u inch
Polarization Key	POLARIZED
Rated Current (Signal)	12 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Material	POLYESTER
Sub Category	Headers and Edge Type Connectors
Terminal Length	0.15 inch
Terminal Pitch	3.81 mm
Termination Type	SOLDER
Total Number of Contacts	3
UL Flammability Code	94V-0
Withdrawl Force-Min	.28912 N
