1-178128-3 データシート

Name: 1-178128-3
Brand: AMP
SKU: 20498624-0000-0000-0000

1-178128-3 - AMP の商品詳細ページです。

２営業日以内に回答いたします

1-178128-3 の詳細情報

型番	1-178128-3
メーカー	AMP
データシート
Additional Feature	ROHS AND ELV COMPLIANT
Body Breadth	0.283 inch
Body Depth	0.898 inch
Body Length	1.169 inch
Body/Shell Style	RECEPTACLE
Connector Type	RECTANGULAR CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	NOT SPECIFIED
Contact Finish - Termination	NOT APPLICABLE
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	10 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Durability	500 Cycles
EMI Shielded	NO
Empty Shell	YES
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	4.8928 N
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	GLASS FILLED POLYETHYLENE
MIL Conformance	NO
Mains Connector Rating	115/230VAC
Mating Contact Pitch	0.2 inch
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Option 2	LATCH
Mounting Type	CABLE
Number Of Connectors	ONE
Number of Ports	1
Number of Rows Loaded	1
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
Panel Mount	NO
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	8 A
Reference Standard	CSA, UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	5.08 mm
Termination Type	CRIMP
Total Number of Contacts	3
Wire Size-Max	14 AWG
Wire Size-Min	28 AWG
Withdrawl Force-Min	.278 N
