N8T26AN データシート

Name: N8T26AN
Brand: AMD
SKU: 240005874-0000-0000-0000

N8T26AN - AMD の商品詳細ページです。

２営業日以内に回答いたします

N8T26AN の詳細情報

型番	N8T26AN
メーカー	AMD
データシート
Additional Feature	DESIGNATED SEND AND RECEIVE; INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION
Control Type	INDEPENDENT CONTROL
Count Direction	UNIDIRECTIONAL
Family	8T
JESD-30 Code	R-PDIP-T16
JESD-609 Code	e0
Load Capacitance (CL)	300 pF
Logic IC Type	BUS TRANSCEIVER
Max I(ol)	0.048 Amp
Number of Bits	4
Number of Functions	1
Number of Ports	2
Number of Terminals	16
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Output Characteristics	3-STATE
Output Polarity	INVERTED
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP16,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5 V
Power Supply Current-Max (ICC)	87 mA
Prop. Delay@Nom-Sup	17 ns
Propagation Delay (tpd)	14 ns
Qualification Status	Not Qualified
Sub Category	Bus Driver/Transceivers
Supply Voltage-Max (Vsup)	5.25 V
Supply Voltage-Min (Vsup)	4.75 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	TTL
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Translation	N/A
