AM7920-1JC
データシート
1
-
- 個
２営業日以内に回答いたします
AM7920-1JC の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | AM7920-1JC |
|---|---|
| メーカー | AMD |
| データシート |  |
| Battery Feed | CONSTANT CURRENT |
| Battery Supply | -19 TO -58 V |
| Hybrid | 2-4 CONVERSION |
| JESD-30 Code | R-PQCC-J32 |
| JESD-609 Code | e0 |
| Length | 13.97 mm |
| Moisture Sensitivity Level | 3 |
| Noise-Max | 12 dBrnC |
| Number of Functions | 1 |
| Number of Terminals | 32 |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Min | 0 Cel |
| PSRR-Min | 30 dB |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | QCCJ |
| Package Equivalence Code | LDCC32,.5X.6 |
| Package Shape | RECTANGULAR |
| Package Style | CHIP CARRIER Meter |
| Peak Reflow Temperature (Cel) | 235 |
| Power Supplies | 5 V |
| Qualification Status | Not Qualified |
| Seated Height-Max | 3.556 mm |
| Sub Category | Analog Transmission Interfaces |
| Supply Current-Max | 8.5 mA |
| Supply Voltage-Nom | 5 V |
| Surface Mount | YES |
| Technology | BIPOLAR |
| Telecom IC Type | SLIC |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | J BEND |
| Terminal Pitch | 1.27 mm |
| Terminal Position | QUAD |
| Width | 11.43 mm |
| 会社名称 | Advanced Micro Devices, Inc. |
|---|---|
| 設立 | 1969 |
| 所在地 | One AMD Place P.O. Box 3453 Sunnyvale, CA 94088-3453，USA |
| URL | http://www.amd.com/ |
