AM29050-25GC データシート

Name: AM29050-25GC
Brand: AMD
SKU: 110115822-0000-0000-0000

AM29050-25GC - AMD の商品詳細ページです。

２営業日以内に回答いたします

AM29050-25GC の詳細情報

型番	AM29050-25GC
メーカー	AMD
データシート
Additional Feature	1KB BRANCH TARGET CACHE
Address Bus Width	32
Bit Size	32
Boundary Scan	NO
Clock Frequency-Max	50 MHz
External Data Bus Width	32
Format	FLOATING POINT
Integrated Cache	NO
JESD-30 Code	S-CPGA-P169
Length	44.704 mm
Low Power Mode	YES
Number of DMA Channels	0
Number of External Interrupts	6
Number of Serial I/Os	0
Number of Terminals	169
On Chip Data RAM Width	0
Operating Temperature-Max	85 Cel
Operating Temperature-Min	0 Cel
Package Body Material	CERAMIC, METAL-SEALED COFIRED
Package Code	PGA
Package Equivalence Code	PGA169,17X17
Package Shape	SQUARE
Package Style	GRID ARRAY Meter
Power Supplies	5 V
Qualification Status	Not Qualified
RAM (words)	0
Seated Height-Max	4.953 mm
Speed	25 rpm
Sub Category	Microprocessors
Supply Current-Max	950 mA
Supply Voltage-Max	5.25 V
Supply Voltage-Min	4.75 V
Supply Voltage-Nom	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	OTHER
Terminal Form	PIN/PEG
Terminal Pitch	2.54 mm
Terminal Position	PERPENDICULAR
Width	44.704 mm
uPs/uCs/Peripheral ICs Type	MICROPROCESSOR, RISC
