AM26LS38DC データシート

Name: AM26LS38DC
Brand: AMD
SKU: 110003655-0000-0000-0000

AM26LS38DC - AMD の商品詳細ページです。

２営業日以内に回答いたします

AM26LS38DC の詳細情報

型番	AM26LS38DC
メーカー	AMD
データシート
Differential Output	YES
Driver Number of Bits	4
Input Characteristics	DIFFERENTIAL SCHMITT TRIGGER
Interface IC Type	LINE TRANSCEIVER
Interface Standard	GENERAL PURPOSE
JESD-30 Code	R-GDIP-T24
JESD-609 Code	e0
Length	31.9405 mm
Number of Functions	4
Number of Terminals	24
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	CERAMIC, GLASS-SEALED
Package Code	DIP
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Qualification Status	Not Qualified
Receive Delay-Max	21 ns
Receiver Number of Bits	4
Seated Height-Max	5.08 mm
Supply Voltage-Max	4.75 V
Supply Voltage-Min	4.25 V
Supply Voltage-Nom	5 V
Surface Mount	NO
Temperature Grade	COMMERCIAL
Terminal Finish	TIN LEAD
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Transmit Delay-Max	12 ns
Width	7.62 mm
