EPF8820ARI208-4 データシート

Name: EPF8820ARI208-4
Brand: ALTERA
SKU: 150061984-0000-0000-0000

EPF8820ARI208-4 - ALTERA の商品詳細ページです。

２営業日以内に回答いたします

EPF8820ARI208-4 の詳細情報

型番	EPF8820ARI208-4
メーカー	ALTERA
データシート
Additional Feature	820 FLIP FLOPS; 672 LOGIC ELEMENTS; CONFIGURABLE I/O OPERATION (3.3V OR 5V)
Clock Frequency-Max	357 MHz
JESD-30 Code	S-PQFP-G208
JESD-609 Code	e0
Length	28 mm
Moisture Sensitivity Level	3
Number of Dedicated Inputs	4
Number of I/O Lines	148
Number of Inputs	152
Number of Logic Cells	672
Number of Outputs	148
Number of Terminals	208
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Organization	4 DEDICATED INPUTS, 148 I/O
Output Function	REGISTERED
Package Body Material	PLASTIC/EPOXY
Package Code	FQFP
Package Equivalence Code	QFP208,1.2SQ,20
Package Shape	SQUARE
Package Style	FLATPACK, FINE PITCH Meter
Peak Reflow Temperature (Cel)	220
Power Supplies	3.3/5,5 V
Programmable Logic Type	LOADABLE PLD
Qualification Status	Not Qualified
Seated Height-Max	4.07 mm
Sub Category	Field Programmable Gate Arrays
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN LEAD
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Width	28 mm
