EPF10K10TC144-3 データシート

Name: EPF10K10TC144-3
Brand: ALTERA
SKU: 150000039-0000-0000-0000

EPF10K10TC144-3 - ALTERA の商品詳細ページです。

２営業日以内に回答いたします

EPF10K10TC144-3 の詳細情報

型番	EPF10K10TC144-3
メーカー	ALTERA
データシート
Clock Frequency-Max	333 MHz
JESD-30 Code	S-PQFP-G144
JESD-609 Code	e0
Length	20 mm
Moisture Sensitivity Level	3
Number of Dedicated Inputs	4
Number of I/O Lines	102
Number of Inputs	102
Number of Logic Cells	576
Number of Outputs	102
Number of Terminals	144
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Organization	4 DEDICATED INPUTS, 102 I/O
Output Function	REGISTERED
Package Body Material	PLASTIC/EPOXY
Package Code	LFQFP
Package Equivalence Code	QFP144,.63SQ,20
Package Shape	SQUARE
Package Style	FLATPACK, LOW PROFILE, FINE PITCH Meter
Peak Reflow Temperature (Cel)	220
Power Supplies	3.3/5 V
Programmable Logic Type	LOADABLE PLD
Propagation Delay	0.5 ns
Qualification Status	Not Qualified
Seated Height-Max	1.6 mm
Sub Category	Field Programmable Gate Arrays
Supply Voltage-Max	5.25 V
Supply Voltage-Min	4.75 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	20
Width	20 mm
