EP910LC30 データシート

Name: EP910LC30
Brand: ALTERA
SKU: 150004444-0000-0000-0000

EP910LC30 - ALTERA の商品詳細ページです。

２営業日以内に回答いたします

EP910LC30 の詳細情報

型番	EP910LC30
メーカー	ALTERA
データシート
Additional Feature	24 MACROCELL; CONFIGURABLE I/O
Architecture	PAL-TYPE
Clock Frequency-Max	33.3 MHz
JESD-30 Code	S-PQCC-J44
JESD-609 Code	e0
Length	16.5862 mm
Number of Dedicated Inputs	12
Number of I/O Lines	24
Number of Inputs	36
Number of Outputs	24
Number of Product Terms	240
Number of Terminals	44
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Organization	12 DEDICATED INPUTS, 24 I/O
Output Function	MACROCELL
Package Body Material	PLASTIC/EPOXY
Package Code	QCCJ
Package Equivalence Code	LDCC44,.7SQ
Package Shape	SQUARE
Package Style	CHIP CARRIER Meter
Peak Reflow Temperature (Cel)	220
Power Supplies	5 V
Programmable Logic Type	OT PLD
Propagation Delay	33 ns
Qualification Status	Not Qualified
Seated Height-Max	4.57 mm
Sub Category	Programmable Logic Devices
Supply Voltage-Max	5.25 V
Supply Voltage-Min	4.75 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	TIN LEAD
Terminal Form	J BEND
Terminal Pitch	1.27 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	16.5862 mm
