EP4CE6E22C8N データシート

Name: EP4CE6E22C8N
Brand: ALTERA
SKU: 150120111-0000-0000-0000

EP4CE6E22C8N - ALTERA の商品詳細ページです。

２営業日以内に回答いたします

EP4CE6E22C8N の詳細情報

型番	EP4CE6E22C8N
メーカー	ALTERA
データシート
Clock Frequency-Max	472.5 MHz
JESD-30 Code	S-PQFP-G144
JESD-609 Code	e3
Length	20 mm
Moisture Sensitivity Level	3
Number of CLBs	392
Number of Inputs	91
Number of Logic Cells	6272
Number of Outputs	91
Number of Terminals	144
Operating Temperature-Max	85 Cel
Operating Temperature-Min	0 Cel
Organization	392 CLBS
Package Body Material	PLASTIC/EPOXY
Package Code	HLFQFP
Package Equivalence Code	QFP144,.87SQ,20
Package Shape	SQUARE
Package Style	FLATPACK, HEAT SINK/SLUG, LOW PROFILE, FINE PITCH Meter
Power Supplies	1.2,1.2/3.3,2.5 V
Programmable Logic Type	FIELD PROGRAMMABLE GATE ARRAY
Qualification Status	Not Qualified
Seated Height-Max	1.65 mm
Sub Category	Field Programmable Gate Arrays
Supply Voltage-Max	1.25 V
Supply Voltage-Min	1.15 V
Supply Voltage-Nom	1.2 V
Surface Mount	YES
Temperature Grade	OTHER
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Width	20 mm
