EP4CE10F17C8N データシート

Name: EP4CE10F17C8N
Brand: ALTERA
SKU: 150123397-0000-0000-0000

EP4CE10F17C8N - ALTERA の商品詳細ページです。

２営業日以内に回答いたします

EP4CE10F17C8N の詳細情報

型番	EP4CE10F17C8N
メーカー	ALTERA
データシート
Additional Feature	IT CAN ASO OPERATE AT 1.2V SUPPLY
Clock Frequency-Max	472.5 MHz
JESD-30 Code	S-PBGA-B256
JESD-609 Code	e1
Length	17 mm
Moisture Sensitivity Level	3
Number of CLBs	10320
Number of Inputs	179
Number of Logic Cells	10320
Number of Outputs	179
Number of Terminals	256
Operating Temperature-Max	85 Cel
Operating Temperature-Min	0 Cel
Organization	10320 CLBS
Package Body Material	PLASTIC/EPOXY
Package Code	LBGA
Package Equivalence Code	BGA256,16X16,40
Package Shape	SQUARE
Package Style	GRID ARRAY, LOW PROFILE Meter
Power Supplies	1.2,1.2/3.3,2.5 V
Programmable Logic Type	FIELD PROGRAMMABLE GATE ARRAY
Qualification Status	Not Qualified
Seated Height-Max	1.55 mm
Sub Category	Field Programmable Gate Arrays
Supply Voltage-Max	1.03 V
Supply Voltage-Min	0.97 V
Supply Voltage-Nom	1 V
Surface Mount	YES
Temperature Grade	OTHER
Terminal Finish	TIN SILVER COPPER
Terminal Form	BALL
Terminal Pitch	1 mm
Terminal Position	BOTTOM
Width	17 mm
