EP1SGX40DF1020C7N データシート

Name: EP1SGX40DF1020C7N
Brand: ALTERA
SKU: 150037937-0000-0000-0000

EP1SGX40DF1020C7N - ALTERA の商品詳細ページです。

２営業日以内に回答いたします

EP1SGX40DF1020C7N の詳細情報

型番	EP1SGX40DF1020C7N
メーカー	ALTERA
データシート
JESD-30 Code	S-PBGA-B1020
JESD-609 Code	e1
Length	33 mm
Moisture Sensitivity Level	3
Number of CLBs	4697
Number of Inputs	624
Number of Logic Cells	41250
Number of Outputs	624
Number of Terminals	1020
Operating Temperature-Max	85 Cel
Operating Temperature-Min	0 Cel
Organization	4697 CLBS
Package Body Material	PLASTIC/EPOXY
Package Code	BGA
Package Equivalence Code	BGA1020,32X32,40
Package Shape	SQUARE
Package Style	GRID ARRAY Meter
Peak Reflow Temperature (Cel)	245
Power Supplies	1.5,1.5/3.3 V
Programmable Logic Type	FIELD PROGRAMMABLE GATE ARRAY
Qualification Status	Not Qualified
Seated Height-Max	3.5 mm
Sub Category	Field Programmable Gate Arrays
Supply Voltage-Max	1.575 V
Supply Voltage-Min	1.425 V
Supply Voltage-Nom	1.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	OTHER
Terminal Finish	TIN SILVER COPPER
Terminal Form	BALL
Terminal Pitch	1 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	30
Width	33 mm
