UDN2981AT データシート

Name: UDN2981AT
Brand: ALLEGRO
SKU: 310095785-0000-0000-0000

UDN2981AT - ALLEGRO の商品詳細ページです。

２営業日以内に回答いたします

UDN2981AT の詳細情報

型番	UDN2981AT
メーカー	ALLEGRO
データシート
Built-in Protections	TRANSIENT
Driver Number of Bits	8
Interface IC Type	BUFFER OR INVERTER BASED PERIPHERAL DRIVER
JESD-30 Code	R-PDIP-T18
JESD-609 Code	e3
Length	22.86 mm
Number of Functions	8
Number of Terminals	18
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-20 Cel
Output Current Flow Direction	SOURCE
Output Current-Max	0.35 A
Output Peak Current Limit-Nom	0.5 A
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP18,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Qualification Status	Not Qualified
Seated Height-Max	5.33 mm
Sub Category	Peripheral Drivers
Supply Voltage-Nom	35 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	OTHER
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Turn-off Time	10 us
Turn-on Time	2 us
Width	7.62 mm

会社名称	Allegro MicroSystems, LLC
所在地	115 Northeast Cutoff,Worcester,MA 01606 United States
URL	http://www.allegromicro.com/
