A3903EEETR-T データシート

Name: A3903EEETR-T
Brand: ALLEGRO
SKU: 400027279-0000-0000-0000

A3903EEETR-T - ALLEGRO の商品詳細ページです。

２営業日以内に回答いたします

A3903EEETR-T の詳細情報

型番	A3903EEETR-T
メーカー	ALLEGRO
データシート
Analog IC - Other Type	STEPPER MOTOR CONTROLLER
JESD-30 Code	S-PDSO-N8
JESD-609 Code	e3
Length	2 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.5 A
Package Body Material	PLASTIC/EPOXY
Package Code	HVSON
Package Equivalence Code	SOLCC8,.08,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3/5 V
Qualification Status	Not Qualified
Seated Height-Max	0.6 mm
Sub Category	Motion Control Electronics
Supply Current-Max (Isup)	2 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	3 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Width	2 mm
