SMP11GY データシート

Name: SMP11GY
Brand: AD
SKU: 290447884-0000-0000-0000

SMP11GY - AD の商品詳細ページです。

２営業日以内に回答いたします

SMP11GY の詳細情報

型番	SMP11GY
メーカー	AD
データシート
Acquisition Time-Nom	5 us
Amplifier Type	SAMPLE AND HOLD CIRCUIT
Analog Input Voltage-Max	18 V
Analog Input Voltage-Min	-18 V
Droop Rate-Max	1 V/s
JESD-30 Code	R-GDIP-T14
JESD-609 Code	e0
Length	19.43 mm
Neg Supply Voltage Limit-Max	-18 V
Neg Supply Voltage-Nom (Vsup)	-15 V
Number of Functions	1
Number of Terminals	14
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	CERAMIC, GLASS-SEALED
Package Code	DIP
Package Equivalence Code	DIP14,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT APPLICABLE
Power Supplies	+-15 V
Qualification Status	Not Qualified
Sample-and-Hold/Track-and-Hold	SAMPLE
Seated Height-Max	5.08 mm
Sub Category	Sample and Hold Circuit
Supply Voltage Limit-Max	18 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT APPLICABLE
Width	7.62 mm

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
