LTM8078EY#PBF データシート

Name: LTM8078EY#PBF
Brand: AD
SKU: 220224069-0000-0000-0000

LTM8078EY#PBF - AD の商品詳細ページです。

２営業日以内に回答いたします

LTM8078EY#PBF の詳細情報

型番	LTM8078EY#PBF
メーカー	AD
データシート
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	40 V
Input Voltage-Min	3 V
Input Voltage-Nom	12 V
JESD-30 Code	S-PBGA-B49
Length	6.25 mm
Number of Functions	2
Number of Terminals	49
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	1.4 A
Output Voltage-Max	10 V
Output Voltage-Min	0.8 V
Package Body Material	PLASTIC/EPOXY
Package Code	FBGA
Package Equivalence Code	BGA49,7X7,32
Package Shape	SQUARE
Package Style	GRID ARRAY, FINE PITCH Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Seated Height-Max	2.42 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	3000 kHz
Temperature Grade	AUTOMOTIVE
Terminal Form	BALL
Terminal Pitch	0.8 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	6.25 mm
