LTM8074EY#PBF データシート

Name: LTM8074EY#PBF
Brand: AD
SKU: 220223658-0000-0000-0000

LTM8074EY#PBF - AD の商品詳細ページです。

２営業日以内に回答いたします

LTM8074EY#PBF の詳細情報

型番	LTM8074EY#PBF
メーカー	AD
データシート
Additional Feature	OUTPUT VOLTAGE RANGE 0.8 TO 12 VOLT
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	40 V
Input Voltage-Min	3.2 V
Input Voltage-Nom	12 V
JESD-30 Code	S-PBGA-B25
JESD-609 Code	e1
Length	4 mm
Moisture Sensitivity Level	3
Number of Functions	1
Number of Terminals	25
Operating Temperature-Max	125 Cel
Operating Temperature-Min	0 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	FBGA
Package Shape	SQUARE
Package Style	GRID ARRAY, FINE PITCH Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.98 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	2200 kHz
Temperature Grade	OTHER
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Form	BALL
Terminal Pitch	0.65 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	4 mm
