LTC1992-1CMS8#PBF データシート

Name: LTC1992-1CMS8#PBF
Brand: AD
SKU: 220224007-0000-0000-0000

LTC1992-1CMS8#PBF - AD の商品詳細ページです。

２営業日以内に回答いたします

LTC1992-1CMS8#PBF の詳細情報

型番	LTC1992-1CMS8#PBF
メーカー	AD
データシート
Amplifier Type	OPERATIONAL AMPLIFIER
Average Bias Current-Max (IIB)	2.0E-6 uA
Common-mode Reject Ratio-Nom	60 dB
Input Offset Voltage-Max	2500 uV
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e3
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Slew Rate-Nom	1.5 V/us
Sub Category	Operational Amplifier
Supply Current-Max	1.5 mA
Supply Voltage Limit-Max	12 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Unity Gain BW-Nom	3000 kHz
Width	3 mm
