LTC1844ES5-3.3#TRPBF データシート

Name: LTC1844ES5-3.3#TRPBF
Brand: AD
SKU: 400050887-0000-0000-0000

LTC1844ES5-3.3#TRPBF - AD の商品詳細ページです。

２営業日以内に回答いたします

LTC1844ES5-3.3#TRPBF の詳細情報

型番	LTC1844ES5-3.3#TRPBF
メーカー	AD
データシート
Adjustability	FIXED
Dropout Voltage1-Max	0.15 V
Dropout Voltage1-Nom	0.09 V
Input Voltage Absolute-Max	7 V
Input Voltage-Max	6.5 V
Input Voltage-Min	1.6 V
JESD-30 Code	R-PDSO-G5
JESD-609 Code	e3
Length	2.9 mm
Line Regulation-Max	0.02 %
Load Regulation-Max	0.02 %
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	5
Operating Temperature, TJ-Max	70 Cel
Operating Temperature, TJ-Min	0 Cel
Output Current1-Max	0.15 A
Output Voltage1-Max	3.3578 V
Output Voltage1-Min	3.2423 V
Output Voltage1-Nom	3.3 V
Package Body Material	PLASTIC/EPOXY
Package Code	VSSOP
Package Equivalence Code	TSOP5/6,.11,37
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	1 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	CMOS
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Voltage Tolerance-Max	1.7 %
Width	1.625 mm
