LT8609EMSE#PBF データシート

Name: LT8609EMSE#PBF
Brand: AD
SKU: 220224374-0000-0000-0000

LT8609EMSE#PBF - AD の商品詳細ページです。

２営業日以内に回答いたします

LT8609EMSE#PBF の詳細情報

型番	LT8609EMSE#PBF
メーカー	AD
データシート
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	42 V
Input Voltage-Min	3 V
Input Voltage-Nom	6 V
JESD-30 Code	S-PDSO-G10
JESD-609 Code	e3
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	10
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	3 A
Output Voltage-Max	42 V
Output Voltage-Min	0.782 V
Package Body Material	PLASTIC/EPOXY
Package Code	HTSSOP
Package Equivalence Code	TSSOP10,.19,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.1 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	2075 kHz
Technology	BIPOLAR
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm
