LT3070EUFD#PBF データシート

Name: LT3070EUFD#PBF
Brand: AD
SKU: 220223416-0000-0000-0000

LT3070EUFD#PBF - AD の商品詳細ページです。

２営業日以内に回答いたします

LT3070EUFD#PBF の詳細情報

型番	LT3070EUFD#PBF
メーカー	AD
データシート
Adjustability	ADJUSTABLE
Dropout Voltage1-Max	0.15 V
Dropout Voltage1-Nom	0.085 V
JESD-30 Code	R-PQCC-N28
JESD-609 Code	e3
Length	5 mm
Load Regulation-Max(%)	1.625 %
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	28
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	5 A
Output Voltage1-Max	1.8 V
Output Voltage1-Min	0.8 V
Package Body Material	PLASTIC/EPOXY
Package Code	HVQCCN
Package Equivalence Code	LCC28,.16X.2,20
Package Shape	RECTANGULAR
Package Style	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	0.8 mm
Sub Category	Other Regulators
Surface Mount	YES
Terminal Finish	Matte Tin (Sn)
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	30
Width	4 mm
