LT3063IDCB#PBF データシート

Name: LT3063IDCB#PBF
Brand: AD
SKU: 400053246-0000-0000-0000

LT3063IDCB#PBF - AD の商品詳細ページです。

２営業日以内に回答いたします

LT3063IDCB#PBF の詳細情報

型番	LT3063IDCB#PBF
メーカー	AD
データシート
Adjustability	ADJUSTABLE
Dropout Voltage1-Max	0.53 V
Dropout Voltage1-Nom	0.3 V
Input-Output Voltage Differential-Max	44.4 V
Input-Output Voltage Differential-Min	1.5 V
JESD-30 Code	R-PDSO-N8
JESD-609 Code	e3
Length	3 mm
Line Regulation-Max (%/V)	0.01554
Load Regulation-Max(%)	0.667 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	0.2 A
Output Voltage1-Max	19 V
Output Voltage1-Min	0.6 V
Package Body Material	PLASTIC/EPOXY
Package Code	HVSON
Package Equivalence Code	SOLCC8,.12,18
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	0.8 mm
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	MATTE TIN
Terminal Form	NO LEAD
Terminal Pitch	0.45 mm
Terminal Position	DUAL
Width	2 mm

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
