- LT1719CS8#PBF
LT1719CS8#PBF
1
-
- 個
２営業日以内に回答いたします
LT1719CS8#PBF の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | LT1719CS8#PBF |
|---|---|
| メーカー | AD |
| Amplifier Type | COMPARATOR |
| Average Bias Current-Max (IIB) | 0 uA |
| Input Offset Voltage-Max | 3500 uV |
| JESD-30 Code | R-PDSO-G8 |
| JESD-609 Code | e3 |
| Length | 4.9 mm |
| Moisture Sensitivity Level | 1 |
| Neg Supply Voltage Limit-Max | -6 V |
| Neg Supply Voltage-Nom (Vsup) | -5 V |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Min | 0 Cel |
| Output Type | OPEN-COLLECTOR |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | SOP |
| Package Equivalence Code | SOP8,.25 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Power Supplies | +-5 V |
| Qualification Status | Not Qualified |
| Response Time-Nom | 7 ns |
| Seated Height-Max | 1.752 mm |
| Sub Category | Comparator |
| Supply Voltage Limit-Max | 6 V |
| Supply Voltage-Nom (Vsup) | 5 V |
| Surface Mount | YES |
| Technology | BIPOLAR |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width | 3.9 mm |
| 会社名称 | アナログ・デバイセズ |
|---|---|
| 設立 | 1965 |
| 所在地 | One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States |
| URL | http://www.analog.com/ |
