DAC1136J データシート

Name: DAC1136J
Brand: AD
SKU: 140201817-0000-0000-0000

DAC1136J - AD の商品詳細ページです。

２営業日以内に回答いたします

DAC1136J の詳細情報

型番	DAC1136J
メーカー	AD
データシート
Analog Output Voltage-Max	10 V
Analog Output Voltage-Min	-10 V
Converter Type	D/A CONVERTER
Input Bit Code	COMPLEMENTARY BINARY, COMPLEMENTARY OFFSET BINARY
Input Format	PARALLEL, WORD
JESD-30 Code	R-XDMA-P31
Length	101.98 mm
Linearity Error-Max (EL)	0.0015 %
Negative Supply Voltage-Nom	-15 V
Number of Bits	16
Number of Functions	1
Number of Terminals	31
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	UNSPECIFIED
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Qualification Status	Not Qualified
Seated Height-Max	10.41 mm
Settling Time-Nom (tstl)	250 us
Supply Voltage-Nom	15 V
Surface Mount	NO
Technology	HYBRID
Temperature Grade	COMMERCIAL
Terminal Form	PIN/PEG
Terminal Position	DUAL
Width	51.18 mm

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
