BUF04GS データシート

Name: BUF04GS
Brand: AD
SKU: 120112586-0000-0000-0000

BUF04GS - AD の商品詳細ページです。

２営業日以内に回答いたします

BUF04GS の詳細情報

型番	BUF04GS
メーカー	AD
データシート
Amplifier Type	BUFFER
Average Bias Current-Max (IIB)	10 uA
Bandwidth (3dB)-Nom	110 MHz
Bias Current-Max (IIB) @25C	5 uA
Input Offset Voltage-Max	4000 uV
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e0
Length	4.9 mm
Neg Supply Voltage Limit-Max	-18 V
Neg Supply Voltage-Nom (Vsup)	-15 V
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Min	0.05 A
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	220
Power Supplies	+-5/+-15 V
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Slew Rate-Min	2000 V/us
Slew Rate-Nom	3000 V/us
Sub Category	Buffer Amplifier
Supply Current-Max	8.5 mA
Supply Voltage Limit-Max	18 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	3.9 mm
