ADP3654ARHZ-RL データシート

Name: ADP3654ARHZ-RL
Brand: AD
SKU: 110269020-0000-0000-0000

ADP3654ARHZ-RL - AD の商品詳細ページです。

２営業日以内に回答いたします

ADP3654ARHZ-RL の詳細情報

型番	ADP3654ARHZ-RL
メーカー	AD
データシート
High Side Driver	NO
Interface IC Type	NAND GATE BASED MOSFET DRIVER
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e3
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Peak Current Limit-Nom	4 A
Package Body Material	PLASTIC/EPOXY
Package Code	HTSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	12 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Sub Category	MOSFET Drivers
Supply Voltage-Max	18 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	12 V
Surface Mount	YES
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Turn-off Time	0.035 us
Turn-on Time	0.03 us
Width	3 mm
