ADP3338AKC-2.5-RL7 データシート

Name: ADP3338AKC-2.5-RL7
Brand: AD
SKU: 110025651-0000-0000-0000

ADP3338AKC-2.5-RL7 - AD の商品詳細ページです。

２営業日以内に回答いたします

ADP3338AKC-2.5-RL7 の詳細情報

型番	ADP3338AKC-2.5-RL7
メーカー	AD
データシート
Adjustability	FIXED
Dropout Voltage1-Max	0.4 V
Dropout Voltage1-Nom	0.19 V
Input Voltage Absolute-Max	8.5 V
Input Voltage-Max	8 V
Input Voltage-Min	2.7 V
JESD-30 Code	R-PDSO-G4
JESD-609 Code	e0
Length	6.5 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	4
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	1 A
Output Voltage1-Max	2.535 V
Output Voltage1-Min	2.465 V
Output Voltage1-Nom	2.5 V
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOT-223
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	240
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	1.8 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	Tin/Lead (Sn85Pb15)
Terminal Form	GULL WING
Terminal Pitch	2.3 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Voltage Tolerance-Max	1.6 %
Width	3.5 mm
