ADM1491EBRMZ データシート

Name: ADM1491EBRMZ
Brand: AD
SKU: 110160155-0000-0000-0000

ADM1491EBRMZ - AD の商品詳細ページです。

２営業日以内に回答いたします

ADM1491EBRMZ の詳細情報

型番	ADM1491EBRMZ
メーカー	AD
データシート
Differential Output	YES
Driver Number of Bits	1
High Level Input Current-Max	1.0E-6 Amp
Input Characteristics	DIFFERENTIAL SCHMITT TRIGGER
Interface IC Type	LINE TRANSCEIVER
Interface Standard	EIA-422-B; TIA-422-B; EIA-485-A; TIA-485-A
JESD-30 Code	S-PDSO-G10
JESD-609 Code	e3
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	10
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Out Swing-Min	1.5 V
Output Low Current-Max	0.004 Amp
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP10,.19,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
Receive Delay-Max	20 ns
Receiver Number of Bits	1
Seated Height-Max	1.1 mm
Sub Category	Line Driver or Receivers
Supply Current-Max	2 mA
Supply Voltage-Max	5.25 V
Supply Voltage-Min	4.75 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Transmit Delay-Max	17 ns
Width	3 mm
