ADCMP580BCPZ-WP データシート

Name: ADCMP580BCPZ-WP
Brand: AD
SKU: 110021911-0000-0000-0000

ADCMP580BCPZ-WP - AD の商品詳細ページです。

２営業日以内に回答いたします

ADCMP580BCPZ-WP の詳細情報

型番	ADCMP580BCPZ-WP
メーカー	AD
データシート
Amplifier Type	COMPARATOR
Average Bias Current-Max (IIB)	30 uA
Bias Current-Max (IIB) @25C	30 uA
Input Offset Voltage-Max	10000 uV
JESD-30 Code	S-XQCC-N16
JESD-609 Code	e3
Length	3 mm
Moisture Sensitivity Level	3
Neg Supply Voltage Limit-Max	-6 V
Neg Supply Voltage-Nom (Vsup)	-5 V
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	UNSPECIFIED
Package Code	HVQCCN
Package Equivalence Code	LCC16,.12SQ,20
Package Shape	SQUARE
Package Style	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	+-5,3.3 V
Qualification Status	Not Qualified
Response Time-Nom	0.18 ns
Seated Height-Max	0.9 mm
Sub Category	Comparator
Supply Voltage Limit-Max	6 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	40
Width	3 mm
