AD96685BH データシート

Name: AD96685BH
Brand: AD
SKU: 110000309-0000-0000-0000

AD96685BH - AD の商品詳細ページです。

２営業日以内に回答いたします

AD96685BH の詳細情報

型番	AD96685BH
メーカー	AD
データシート
Amplifier Type	COMPARATOR
Average Bias Current-Max (IIB)	13 uA
Bias Current-Max (IIB) @25C	10 uA
Input Offset Voltage-Max	3000 uV
JESD-30 Code	O-MBCY-W10
JESD-609 Code	e0
Neg Supply Voltage Limit-Max	-6.5 V
Neg Supply Voltage-Nom (Vsup)	-5.2 V
Number of Functions	1
Number of Terminals	10
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Output Type	OPEN-EMITTER
Package Body Material	METAL
Package Code	TO-100
Package Equivalence Code	CAN10,.23
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5,-5.2 V
Qualification Status	Not Qualified
Response Time-Nom	2.5 ns
Sub Category	Comparators
Supply Voltage Limit-Max	6.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	OTHER
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	WIRE
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
