AD8202YRMZ データシート

Name: AD8202YRMZ
Brand: AD
SKU: 110018698-0000-0000-0000

AD8202YRMZ - AD の商品詳細ページです。

２営業日以内に回答いたします

AD8202YRMZ の詳細情報

型番	AD8202YRMZ
メーカー	AD
データシート
Amplifier Type	OPERATIONAL AMPLIFIER
Common-mode Reject Ratio-Nom	80 dB
Input Offset Voltage-Max	2000 uV
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e3
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Slew Rate-Nom	0.28 V/us
Sub Category	Operational Amplifier
Supply Current-Max	1 mA
Supply Voltage Limit-Max	12.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
