AD8021ARZ-REEL7 データシート

Name: AD8021ARZ-REEL7
Brand: AD
SKU: 110018184-0000-0000-0000

AD8021ARZ-REEL7 - AD の商品詳細ページです。

２営業日以内に回答いたします

AD8021ARZ-REEL7 の詳細情報

型番	AD8021ARZ-REEL7
メーカー	AD
データシート
Amplifier Type	OPERATIONAL AMPLIFIER
Average Bias Current-Max (IIB)	10.5 uA
Common-mode Reject Ratio-Nom	98 dB
Input Offset Voltage-Max	1000 uV
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e3
Length	4.9 mm
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-13.2 V
Neg Supply Voltage-Nom (Vsup)	-5 V
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Slew Rate-Nom	420 V/us
Sub Category	Operational Amplifier
Supply Voltage Limit-Max	13.2 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3.9 mm
