AD7788ARMZ データシート

Name: AD7788ARMZ
Brand: AD
SKU: 110002404-0000-0000-0000

AD7788ARMZ - AD の商品詳細ページです。

２営業日以内に回答いたします

AD7788ARMZ の詳細情報

型番	AD7788ARMZ
メーカー	AD
データシート
Analog Input Voltage-Max	5.25 V
Analog Input Voltage-Min	0.1 V
Converter Type	ADC, DELTA-SIGMA
JESD-30 Code	S-PDSO-G10
JESD-609 Code	e3
Length	3 mm
Linearity Error-Max (EL)	0.005 %
Moisture Sensitivity Level	1
Number of Analog In Channels	1
Number of Bits	16
Number of Functions	1
Number of Terminals	10
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Bit Code	BINARY, OFFSET BINARY
Output Format	SERIAL
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP10,.19,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3/5 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Sub Category	Analog to Digital Converters
Supply Voltage-Nom	3 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
