AD7574JN データシート

Name: AD7574JN
Brand: AD
SKU: 110016471-0000-0000-0000

AD7574JN - AD の商品詳細ページです。

２営業日以内に回答いたします

AD7574JN の詳細情報

型番	AD7574JN
メーカー	AD
データシート
Analog Input Voltage-Max	10 V
Analog Input Voltage-Min	-20 V
Conversion Time-Max	15 us
Converter Type	A/D CONVERTER
JESD-30 Code	R-PDIP-T18
JESD-609 Code	e0
Length	22.48 mm
Linearity Error-Max (EL)	0.293 %
Number of Analog In Channels	1
Number of Bits	8
Number of Functions	1
Number of Terminals	18
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Output Bit Code	BINARY
Output Format	PARALLEL, 8 BITS
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP18,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT APPLICABLE
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	4.48 mm
Sub Category	Analog to Digital Converters
Supply Voltage-Nom	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT APPLICABLE
Width	7.62 mm

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
