AD7533KR データシート

Name: AD7533KR
Brand: AD
SKU: 110002271-0000-0000-0000

AD7533KR - AD の商品詳細ページです。

２営業日以内に回答いたします

AD7533KR の詳細情報

型番	AD7533KR
メーカー	AD
データシート
Converter Type	D/A CONVERTER
Input Bit Code	BINARY, OFFSET BINARY
Input Format	PARALLEL, WORD
JESD-30 Code	R-PDSO-G16
JESD-609 Code	e0
Length	10.3 mm
Linearity Error-Max (EL)	0.1 %
Moisture Sensitivity Level	1
Number of Bits	10
Number of Functions	2
Number of Terminals	16
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP16,.4
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	240
Power Supplies	15 V
Qualification Status	Not Qualified
Seated Height-Max	2.65 mm
Settling Time-Max	0.8 us
Settling Time-Nom (tstl)	0.8 us
Sub Category	Other Converters
Supply Current-Max	2 mA
Supply Voltage-Nom	15 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	7.5 mm
