AD75004KN の詳細情報

型番	AD75004KN
メーカー	AD
データシート
Analog Output Voltage-Max	5 V
Analog Output Voltage-Min	-5 V
Converter Type	D/A CONVERTER
Input Bit Code	BINARY
Input Format	PARALLEL, 8 BITS
JESD-30 Code	R-PDIP-T24
JESD-609 Code	e0
Length	30.988 mm
Linearity Error-Max (EL)	0.0183 %
Negative Supply Voltage-Nom	-12 V
Number of Bits	12
Number of Functions	4
Number of Terminals	24
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP24,.6
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	240
Power Supplies	+-12 V
Qualification Status	Not Qualified
Seated Height-Max	6.35 mm
Settling Time-Max	4 us
Settling Time-Nom (tstl)	2 us
Sub Category	Other Converters
Supply Current-Max	30 mA
Supply Voltage-Nom	12 V
Surface Mount	NO
Technology	BICMOS
Temperature Grade	COMMERCIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	15.24 mm
