AD7400AYRWZ
データシート
1
-
- 個
２営業日以内に回答いたします
AD7400AYRWZ の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | AD7400AYRWZ |
|---|---|
| メーカー | AD |
| データシート |  |
| Additional Feature | IT ALSO REQUIRES 4.5V 5.5V SUPPLY |
| Analog IC - Other Type | ANALOG CIRCUIT |
| JESD-30 Code | R-PDSO-G16 |
| JESD-609 Code | e3 |
| Length | 10.3 mm |
| Moisture Sensitivity Level | 3 |
| Number of Functions | 1 |
| Number of Terminals | 16 |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -40 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | SOP |
| Package Equivalence Code | SOP16,.4 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Power Supplies | 3.3/5,5 V |
| Qualification Status | Not Qualified |
| Seated Height-Max | 2.65 mm |
| Sub Category | Other Analog ICs |
| Supply Current-Max (Isup) | 13 mA |
| Supply Voltage-Max (Vsup) | 5.5 V |
| Supply Voltage-Min (Vsup) | 3 V |
| Supply Voltage-Nom (Vsup) | 3.3 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | AUTOMOTIVE |
| Terminal Finish | Matte Tin (Sn) |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width | 7.5 mm |
| 会社名称 | アナログ・デバイセズ |
|---|---|
| 設立 | 1965 |
| 所在地 | One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States |
| URL | http://www.analog.com/ |
